A, POWER ON/OFF

Press the fire button 5 times in quick succession to turn the device on and off. After switch on,OLED display THREE logo and software version number at stand by mode

(Note:

Please adjust the wattage to a proper range to match the atomizer you used before using.)

B,Vaping

While the device is power on , just keep pressing the fire button to vape  (Firing timeout :10 Seconds)

While the device is power on, the OLED screen default display VW mod.

C. General Functions

Enter Into The Main Menu Press the fire button 3 times to enter into the main menu. Press the right and left regulatory buttons to switch among different functions. Press the fire button to confirm.

D. Power Mode

In the main menu, switch to “

Intensity Setting In Power Mode

In the main menu, switch to intensity setting, press fire button to confirm. Press right and left buttons to switch among below 4 modes. In user mode,press fire button to switch among each setting columns. Press right and left buttons to adjust the wattage. After setup is completed, press fire button to switch to “EXIT”. Press right or left button to confirm.

Norm Mode: Maintains the currently set power.

Hard Mode: 30% higher than the currently set power.

Soft Mode: 20% lower than the currently set power.

User Mode: Customize the power output for the first three seconds of each puff, with each setting column representing half a second.

D. Temp Mode

Ni/Ti /SS/TCR M1/TCR M2

In the main menu, switch to “T” setting, press fire button to confirm. Press right and left buttons to switch among Ni/Ti/SS/M1/M2 modes. Press fire button to confirm. Press right button, when “W” flashing, press right and left buttons to adjust wattage.  Press left button, when “°F” or “°C” flashing, press right and left buttons to adjust temperature value. The temperature unit will cycle between °F and °C when the minimum or maximum temperature is reached. In the temperature control mode to replace the heating wire, when the new heating wire resistance and the previous heating wire resistance difference greater than or equal to 0.2ohm, the screen appears the following tips. Press + to choose and confirm new coil. Press - to choose and confirm same coil.

F. TCR Mode (M1, M2)

With the TCR (Temperature Coefficient of Resistance) function available now, you can customize your temperature control coils(Ni, Ti, SS) on your own. In the main menu, switch to “T” setting, press fire button to confirm. Switch to M1/M2 modes. Press fire button to confirm.

How to set the TCR?

In the main menu, switch to “TCR” mode indication, press fire button to confirm. Press fire button to choose between TCR M1, TCR M2. Press right/left buttons to select certain parameter. After setup is completed, press fire button to switch to “EXIT”. Press right or left button to confirm.

G. Puff counter

In any mode, the screen shows the number of puffs. If a puff more than 0.8s, it will be recorded as one puff. The device can remember the value even if you remove the battery. The default number is “0000”. When the number reaches “9999”, it will be cleared automatically.

H. How to clear the puff value manually?

Press the fire button 3 times in 2s to enter the menu, choose  icon to enter the   setting, press fire button to confirm your choice.

I. Set the standby mode

Press the fire button 3 times in 2s to enter the menu,choose icon, use + and - button to choose “Screen Time” area, there are 4 preset choices, press fire button to confirm your choice, the screen will enter standby mode at the selected time.
